FŐ TULAJDONSÁGOK
Felhasználási terület
Mérettartomány
DN50 - DN1200
Test anyaga
Gömbgrafitos öntöttvas
Bevonat
Epoxipor-bevonat
Csavarok
Rozsdamentes acél A2
Anyák
Rozsdamentes acél A4
Tömítés
EPDM gumi
| DN | Cikkszám | Átfogás (mm) Dmin – Dmax | Csavarok | Kötőrudak száma | Szegmensek száma (x2) | |
| db | méret | |||||
| 50 | 63-70 | 4 | M12 | 4 | 2 | |
| 60 | 72-80 | 6 | M12 | 6 | 3 | |
| 80 | 70901670108000 | 98-104 | 6 | M12 | 6 | 3 |
| 100 | 709016702100000 | 118-124 | 6 | M12 | 6 | 3 |
| 125 | 144-154 | 6 | M12 | 6 | 3 | |
| 150 | 709016704150000 | 170-180 | 6 | M12 | 8 | 3 |
| 175 | 709016704175000 | 196-212 | 8 | M12 | 8 | 4 |
| 200 | 709016706200000 | 222-238 | 8 | M12 | 8 | 4 |
| 225 | 248-246 | 8 | M12 | 12 | 4 | |
| 250 | 70901670827500A | 274-292 | 8 | M14 | 12 | 4 |
| 275 | 70901670827500B | 304-322 | 8 | M14 | 12 | 4 |
| 300 | 709016711300000 | 326-344 | 8 | M16 | 12 | 4 |
| 325 | 709016711325000 | 355-370 | 8 | M16 | 16 | 4 |
| 350 | 378-396 | 8 | M16 | 16 | 4 | |
| 400 | 709016712540000 | 429-455 | 10 | M16 | 15 | 5 |
| 425 | 709016714425000 | 455-475 | 10 | M16 | 15 | 5 |
| 450 | 709016714450000 | 480-510 | 10 | M16 | 15 | 5 |
| 500 | 70901671500-E | 532-560 | 10 | M16 | 20 | 5 |
| 600 | 70901671600-E | 634-662 | 20 | M16 | 25 | 5 |
| 625 | 645-670 | 24 | M16 | 25 | 6 | |
| 650 | 709016725650000 | 690-715 | 24 | M16 | 25 | 6 |
| 700 | 738-768 | 24 | M16 | 24 | 6 | |
| 750 | 709016735750000 | 814-840 | 32 | M16 | 25 | 8 |
| 800 | 842-882 | 32 | M16 | 32 | 8 | |
| 1000 | 1048-1090 | 36 | M16 | 36 | 9 | |
| 1200 | 1256-1298 | 40 | M16 | 40 | 10 | |
